Knuckle joint press BARNAUL K849S

Offer #1791

Knuckle joint press BARNAUL K849S
Manufacturer: Barnaul
Made in: Russia

Specification:

Press force at the end of stroke: 2000 t
Slide stroke: 200 mm
Number of slide strokes per minute: 17
Adjustment of interstamping space: 15 mm
Max. distance between table and slide in its lower position: 830 mm
Distance between guides in daylight: 1040 mm
Bolster plate dimensions:
 -From front - to back: 1300 mm
 -From right - to left: 1270 mm
Size of the opening in the table - diameter: 130 mm
Slide dimensions:
 -From front - to back: 800 mm
 -From right - to left: 1250 mm
Main electric motor:
 -Type: АС 82-4
 -Power: 55 kW
 -RPM: 1380
Electric motor of adjustment:
 -Type: АО 52-6
 -Power: 4,5 kW
 -RPM: 950
Press weight: 75107 kg
