Offer #1674
Hydraulic press Gigant G2-250
YOM: 1993
Manufacturer: Gigant
Made in: Italy
Specification:
Press capacity: 250 tons
Slide capacity: 250 tons
Capacity on reverse stroke: 25 tons
Table or slide stroke: 400 mm
Max. working pressure: 200 bar
Pump: 145 + 85 l/min
Speed of table feed: 400 mm/sec
Working table speed: 20 mm/sec
Speed of reverse table stroke: 250 mm/sec
Electric motor: 44 kW
Rotation frequency: 1500 rpm
Voltage: 380 V; 50 Hz
Max. clearance (distance) between bolster plate and die: 600 mm
CLearance between columns: 870 mm
Stationary table dimensions: 850 x 950 mm
Moving table dimensions: 850 x 950 mm
Press dimensions: 2000 x 1800 H3700
Press weight: 10 tons
