Offer #541
Thread milling machine ZFWVG 250/3Wx800
Serial No: 263128/6
Country of origin: Germany
Manufacturer: WMW
Specification:
Work-piece diameter over:
-Bed: 500 mm
-Saddle: 250 mm
Milling length: 800 mm
Max module: 7
Center height over bed: 260 mm
Workpiece spindle bore: 102 mm
Workpiece turning speeds: 0,0034 - 2,65 U/min
Feeds-rolls: 0,027 - 5,66 mm/U
Longitudinal feeds, infinitely variable 0,3 - 198 mm/min
Main drive: 4,0 kW
Electrics-voltage/frequency: 380 / 50 V/Hz
Total power requirement: 9,5 kW
Dimensions: 2800x2500x1600 mm
Total weight: 3500 kg
