Offer #970
Vertical turning lathe TOS SKJ 8 F
YOM: 1988
Made in: Czechoslovakia
Manufacturer: TOS HULIN
Specification:
Swing: 1050 mm
Table diameter: 800 mm
Table speed range per 1 min: 1,5-520 mm
Circle diameter: 1050 mm
Turning diameter with side support: 800 mm
Max. work-piece height: 630 mm
Max. work-piece weight: 2500 kg
Rapid traverse: 3500 mm/min
Rotational speed:
-Stage I: 3-85 rot/min
-Stage II: 6-205 rot/min
-Stage III: 13-400 rot/min
Main motor power: 30 kW
Machine weight: 12 tons
