Offer #1287
Horizontal lathe KRAMATORSK KZH 16166
Manufacturer: Kramatorsk
Made in: Russia
Machinery is dismantled.
Specification:
Max. work-piece diameter above the bed: 1600 mm
Max. work-piece diameter above the support: 1250 mm
Max. work-piece length: 8000 mm
Max. work-piece weight: 40000 kg
Height of centers: 850 mm
Max. spindle torque: 10000 kgm
Size of inner taper of spindle headstock according to GOST 8593-57: 110x1:7
Center in the spindle headstock: 110x75 degrees
Number of spindle revs at installing the work-piece of max. weight: 10 rpm
Spindle rotation range: 0,63-160 rpm
Center of quill of tailstock according to GOST 18259-72: 7032-0094
Diameter of quill of tailstock: 360 mm
Rapid travel speed of tailstock: at least 3700 m/min
Max. moving out of quill: 360 mm
Speed of rapid moving out of quill: at least 0,35 m/min
