Offer #2121
Deep hole drilling machinery RYAZAN RT60190
YOM: 1984
Manufacturer: RYAZAN
Made in: Russia
Specification:
Diameters of work-pieces to be clamped:
-In a collet chuck: 156 mm
-In a steady rest: 100-300 mm
Diameters of work-piece holes (boring): 80-250 mm
Work-piece length:
-Min: 600 mm
-Max: 2000 mm
Height of the centers over the bed guides: 315 mm
Spindle headstock rotation frequency: 40-500 rpm
Amount of spindle headstock speeds: 12
Range of working feeds: 3-3000 mm/min
Speed of rapid headstock stem feed: 3000 mm/min
Machine dimensions:
-Length: 9500 mm
-Width: 2550 mm
-Height: 1550 mm
Machine weight: 15300 kg
Description:
Designed for boring holes with diameters of 80-250 mm in the details such as shafts and cylinders with outer diameters of 100-300 mm, length 600-2000 mm.
