Offer #2147
Jig borer SIP HYDROPTIC 8P
Manufacturer: SIP
Made in: Switzerland
It is in a nice working condition.
Specification:
Table length: 1570 mm
Table width: 1024 mm
Longitudinal travel (X-axis): 1400 mm
Transversal travel (y axis): 1000 mm
Max. table load: 2000 kg
Stroke of drilling spindle (Z-axis): 300 mm
Max. bore diameter: 250 mm
Spindle speeds:
-Number (steps): 18
-From: 40 rpm
-Up to: 2000 rpm
Feeds:
-Table:
-Up to: 300 mm/min
Drill spindle slide:
-Number (steps): 8
-From: 0.02 mm/r
-Up to: 0.30 mm/r
Rapid traverse:
-Table:
-Longitudinal: 2000 mm/min
-Transversal: from 2000 mm/min
Distance between columns: 1450 mm
Voltage: 50 Hz, 3x380 Volt
Overall machine dimensions:
-Length: 4150 mm
-Width: 2700 mm
-Height: 3180 mm
Machinery weight: 16900 kg
Machinery weight: 16900 kg
